快脱式扭力扳手 Micro Torque Wrench (Lock-up Setting)- 1/4″, 3/8″, 1/2″, 3/4″

快脱式扭力扳手 Micro Torque Wrench (Lock-up Setting)- 1/4″, 3/8″, 1/2″, 3/4″

  • Adjustable torque model for clockwise tightening.
    • The model applied on 1/4″, 3/8″ 1/2″, 3/4″ Drive, apply for N.m and ft lbs (Newton-metre, foot-pound)
    • Clés dynamométrique
    • Klucz dynamometryczny
    • Drehmomentschlüssel
    • Llaves dinamométrica
    • مفتاح العزم
    • ประแจวัดแรงบิด
    • 扭力扳手
    • 2170GN/ 3170GN/ 3171GN/ 4170GN/ 4171GN/ 6170GN/ 2170GI/ 3170GI/ 3171GF/ 4170GF/ 4171GF/ 6170GF
    • Sensible and audible alarm on reaching preset torque value
    • Plastic Green Handle
    • DIN EN ISO 6789
    • DIN 3120 – ISO 1174
Torque Wrench GN series Model
  • A torque wrench is an essential tool for ensuring that bolts are tightened to the correct specification. They are made from chrome vanadium steel for strength and durability, and have a ratchet head that allows them to be used for clockwise or anti-clockwise torque. The handle is knurled for a good grip, and when the required torque setting is reached, the wrench produces an audible click and a slight release of tension.
Clicker torque wrench
DRIVEITEM NO.CAPACITY
N · m
ITEM NO.CAPACITY
FT-LB
(INCH-LB)
L
mm / inch
porduct sizeicon1
g
1/4"2170GN6-302170GI40-250
INCH · LB
290 / 13-3/4"900扭力板手用小圖示
3/8"3170GN6-303170GI40-250
INCH · LB
295 / 13-3/4"900扭力板手用小圖示
3/8"3171GN20-1103171GF15-80
FT · LB
380 / 15"1180扭力板手用小圖示
1/2"4170GN40-2104170GF30-150
FT · LB
535 / 21"2100扭力板手用小圖示
1/2"4171GN70-3504171GF50-250
FT · LB
650 / 25-1/2"3110扭力板手用小圖示
3/4"6170GN100-5006170GF50-300
FT · LB
865 / 34"4730扭力板手用小圖示
BLOW CASE FOR EACH
